Zillertalbahn level crossing with coupled traffic signal system
October 2026

New solution for greater safety and optimised traffic flow.

Together with Zillertaler Verkehrsbetriebe AG, the operator of the Zillertal Railway, we have implemented a solution – the first of its kind in Austria – to optimise traffic flow at a complex level crossing.

The starting situation: the combination of a heavily used road section on a priority road and an adjoining level crossing posed a particular challenge for traffic flow. At times of high traffic volume, it was difficult for vehicles from subordinate roads to enter the priority road within the opening window of the level crossing.

To specifically improve this traffic flow, upstream traffic lights were installed on the priority road as a partial traffic signal system (UVLSA). These are coupled with the level crossing's signals and coordinated accordingly. The UVLSA logic was integrated directly into the control of the level crossing protection system (EKSA), so no separate traffic signal system (VLSA) controller was required. As a result, traffic on the priority road can be stopped briefly and in a targeted way, allowing vehicles from the subordinate roads to safely enter the priority road.

This solution was preceded by an intensive nine-month planning and traffic analysis phase. The local traffic situation was comprehensively analysed and a technical solution tailored to the specific conditions was developed.

With its implementation, a solution unique in Austria was created that efficiently coordinates rail and road traffic while also contributing to improved traffic flow.

The project once again demonstrates how thorough planning, sound traffic analysis and tailored technical solutions can deliver safe and efficient outcomes even for complex traffic situations.

Glossary (terms used in Austrian railway and road-traffic regulation, cited here by their German abbreviations): EKSA (Eisenbahnkreuzungssicherungsanlage) – level crossing protection system · UVLSA (Unvollständige Verkehrslichtsignalanlage) – partial traffic signal system · VLSA (Verkehrslichtsignalanlage) – traffic signal system
